Product details
- Material: aluminium alloy, stainless steel and POM for high structural strength, wear resistance and corrosion resistance.
- Sheave: 100 mm outer diameter and 55 mm inner diameter, for rope diameter up to 55 mm.
- Capacity: 36 kN limit load and 22 kN working load.
- Efficiency 96 % for smooth running.
Specifications
| Material | Aluminium alloy, stainless steel, POM |
|---|---|
| Size | 510 × 120 × 98 mm |
| Sheave | Inner diameter 55 mm, outer diameter 100 mm |
| Limit load | 36 kN |
| Working load | 22 kN |
| Efficiency | 96 % |
| Rope diameter | ≤55 mm |
| Weight | 1320 g |
| Standard | XF494-2023 |
Safety notes
- Inspect the product before every use and stop using it immediately if any wear or damage is found.
- Select the product for the application and use it only with compatible certified equipment.
- This is personal protective equipment — do not modify it and do not use it beyond its service life.
Wholesale, OEM and custom requirements: contact our team for pricing, lead time and certification documents.
